How to wire the pulse signal output of a quality flowmeter and distinguish between active signal output and passive signal output The pulse signal output from the mass flowmeter to the flow computer can be an active signal or a passive signal, determined by the type of signal received by the flow computer. Generally, it is an active signal. The active and passive connections of E+H flowmeter and Emerson flowmeter are the same, but there is a difference in signal type selection during configuration. The Huanaidan E+H flowmeter (with 1 current and 2 pulse outputs) has two sets of pulse output terminals, namely 22+and 23-, 24+and 25-, which directly correspond to the positive and negative terminals of the flow computer pulse input. The Emerson flowmeter (1 current, 2 pulse outputs) has two sets of pulse output terminals, 3+, 4-, 5+, and 6-, which correspond directly to the positive and negative terminals of the flow computer pulse input.

2. Doppler flowmeter

3. What is flowmeter F+F -? For flow meters, F+and F - represent the positive and negative polarity signal output ports, respectively. When the fluid passes through the flowmeter, it will generate weak electrical signals from Congtong, which are output through the F+and F - ports. The F+port outputs a positive polarity signal, while the F - port outputs a negative polarity signal. These signals can be used to calculate the flow resistance of Zheng.

4. What are the types of output signals for DQD-65 electromagnetic flowmeter?

DQD-65 electromagnetic flowmeter provides multiple output signal options, including but not limited to the following

1. Analog current signal: This flowmeter can output a 4-20mA analog current signal, where

2. Analog voltage signal: In addition to analog current signal, DQD-65 electromagnetic flowmeter can also provide 0-5V or 0-10V analog voltage signal as flow output.

3. Digital signal: Some DQD-65 electromagnetic flow meters have digital output function, which can transmit flow data in digital form to the monitoring system or computer through communication protocols such as RS485

5 and MODBUS. Please note that the actual available output signal types and parameters may vary depending on the DQD-65 electromagnetic flowmeter of different models or manufacturers. To obtain accurate output signal information, it is recommended to refer to the technical specifications or user manual of the specific device.

5. How can the output signal of the flowmeter be used for on-site flow display and shared control of the water pump?

The output signal of the flowmeter can be used for on-site flow display and shared control of the water pump through a signal distributor or PLC. Signal type and processing method: Flow meters commonly use 4-20mA analog signals or pulse/frequency signal outputs. To achieve display and control sharing, the core is to use a signal distributor to convert one input signal into two identical output signals: one is sent to the on-site display instrument, and the other is sent to the water pump controller

2. Specific implementation plan: Plan 1: Signal distributor method • Install signal distributor (such as P+F, Weidmuller and other brand isolated signal distributors) • Con
