1. Cologne flowmeter 485 wiring method

When operating the Cologne flow disturbance meter, the 485 wiring steps should strictly follow the following guidelines. Firstly, prepare the RS-485 communication cable, which typically consists of three wires: two for data transmission (A and B), and one for grounding. Secondly, connect the A and B wires to the RS485+and RS485- terminals marked on the flow meter according to the correct polarity. Ensure that the cables of the slow molding car are undamaged and in good contact. Next, extend the A and B wires of the same RS-485 communication cable to the control system. Similarly, follow the correct polarity to connect the A and B wires to the corresponding RS485 interface terminals of the control system. Then, connect the grounding wire to the grounding terminals of the flow meter and control system to ensure stable signal transmission and equipment safety. After completing the physical connection, configure the correct communication parameters in the control system. This usually includes setting the baud rate (such as 9600, 19200, etc.), parity (even parity or no parity), stop bit (usually 1 or 2 bits), and flow control. Finally, perform system debugging and testing. Check if the communication between the flowmeter and the control system is normal and if the data is transmitted accurately. If necessary, refer to the equipment manual to adjust the relevant settings until communication is stable and data is accurate.

2. Detailed explanation of the usage steps of Cologne metal tube rotor flowmeter

The use of Cologne metal tube rotor flowmeter requires strict adherence to operating specifications, with the core being installation compliance, flow control stabi

lity, and continuous operation monitoring.

. 1. Preparation for appearance and matching inspection before installation: Before use, it is necessary to confirm that the appearance of the flowmeter is not damaged or deformed, and that the flange or threaded interface is not loose. Special attention should be paid to whether the medium type, temperature, and pressure range on the flowmeter label match the on-site working conditions, in order to avoid damage caused by excessive use. Flow direction and verticality calibration: The flow direction of the medium must be consistent with the direction marked on the flowmeter. During installation, a level should be used to assist in ensuring that the verticality deviation of the measuring tube is ≤ 2 °. Tilting can cause the float to rub against the tube wall, affecting measurement accuracy. 2. Installation implementation points: Pipeline layout specifications: A straight pipe section with a diameter of ≥ 5 times the diameter should be reserved upstream of the flowmeter, and a diameter of ≥ 3 times the diameter should be reserved downstream. If the medium contains impurities, a 40 mesh filter should be installed at the inlet to prevent particles from sticking to the float. Sealing operation details: When connecting flanges, diagonal cross fastening bolts are required, and 0.5mm thick graphite composite gaskets are used. For pipe diameters above DN50, it is recommended to use the segmented pre tightening method and increase the torque to the specified value in three stages. 3. Debugging and operation control: Gradual valve opening operation: When the medium is first introduced, the upstream valve opening speed should be controlled to rotate 1/4 turn every 10 seconds. Observe the
